The DEWALT DCS727 XR FlexVolt Slide Mitre Saw features a cam action mitre lock function that allows the user to quickly adjust the angle between 0-50° left and 0-60° right. Its large dual sliding fence provides maximum support in large material cuts, at any angle or combination of angles. Includes an integrated short stop for repetitive cuts. Linear horizontal rails utilise bronze guides to provide maximum precision when cutting materials up to 305mm wide. An innovative grooving stop allows for adjustment of the cutting depth, ideal for grooving and rebating applications. The XPS Shadow line cut indicator provides fast accurate alignment of the blade while illuminating the workpiece for increased productivity. AIRLOCK compatible dust extraction, for improved cut line visibility and a cleaner working area. Compatible with the Wireless Tool Control system.

Supplied with:

1 x 54V XR FLEXVOLT 250mm Mitre Saw
2 x Base Extensions
1 x Blade Wrench
1 x 36 Tooth Blade
1 x Material Clamp
2 x DCB546 6Ah/2Ah Battery
1 x DCB118 Charger

Key Features

• The innovative grooving stop allows the adjustment of the cutting depth for grooving and rebating applications
• The large dual sliding fence gives maximum support in large material cuts at any angle or combination of angles
• Linear 32mm horizontal rails with roller bearings provide maximum precision when cutting materials up to 305 mm wide
• XPS Shadow line cut indicator provides fast accurate alignment of the blade while illuminating the work piece for increased productivity
• Machined side handles meet latest IEC table requirements and improve portability and handling whilst providing a stable, base for wider materialIntuitive bevel lock with machined stops provides accurate and simple setting of bevel angles up to 49° left and right
• Wireless Tool Control allows direct connection to the vac which provides increased runtime and improves efficiency
• AirLock compatible dust extraction improves cut line visibility and provides cleaner and safer jobsites

Specification

Blade Bore [Metric]: 30 mm
Blade Speed: 4300 rpm
Max. Cutting Capacity (45°/45°) [Metric]: 210 x 50 mm
Max. Depth of Cut [Metric]: 150 x 28 mm
Saw Blade Thickness [Metric]: 2.16 mm
Max. Cutting Capacity (90°/90°) [Metric]: 305 x 77 mm
Product Width [Metric]: 480 mm
Battery Capacity: 6 Ah
No Load Speed (RPM): 4300
Max. Cutting Capacity (45°/90°) [Metric]: 210 x 77 mm
Product Height [Metric]: 460 mm
Product Weight [Metric]: 20.5 Kg
Blade Diameter [Metric]: 250 mm
Weight (Including Battery) [Metric]: 22 Kg
Voltage: 54 V
Max. Cutting Capacity (90°/45°) [Metric]: 305 X 50 mm
Power Source: Cordless
Product Length [Metric]: 770 mm
