The Makita HS7100 110V 190mm Circular Saw has been developed as the successor to the 5705R. It features a compact and lightweight design without riving knife. It has an ergonomically designed soft grip covered with non-slip elastomer and a large ejection port. The single action lever allows the rip fence to be attached and removed easily, and there is a positive stop at 45°. There is also a maximum cutting angle up to 50° and a precision bevel adjustment can be made at 45°.

Supplied with:

1 x HS7100 110V 190mm Circular
1 x Parallel Guide
1 x Dust Nozzle Set
1 x TCT Saw Blade
1 x Hex Wrench

Key Features

• Low noise level for pleasant work.
• Well-balanced and lightweight for superior handling and performance
• Aluminium die-cast safety cover for high durability and long tool life

Specification

Continuous Input Power: 1400 W
No load speed: 5500 min⁻¹
Max. Cutting Depth at 90°: 67 mm
Max. Cutting Depth at 45°: 48,5 mm
Max. Cutting Depth at 50°: 43,5 mm
Blade Diameter: 190 mm
Bore Size (Arbor Diameter): 20 / 30 mm
Power Supply Cord: 2,5 m
Sound Power Level (LWA): 108 dB(A)
Sound Pressure Level (LpA): 100 dB(A)
Noise Uncertainty (K Factor): 3 dB(A)
Weight Without Cable: 4,0 kg
Product Dimensions (L x W x H): 310 x 246 x 258 mm
Max Output Power: 2200 W
Max. Bevel Range (Right): 0 - 50 º
